EtherCAT Kommunikation
Setting the parameters of analog I/O
2 analog inputs −10 ... +10 V (16 bits) − EPM−S406
10
l
490 EDSIO1000 EN 7.0
10.5.5 2 analog inputs −10 ... +10 V (16 bits) − EPM−S406
Parameter data
Subindex Name Description/value Lenze
01 Diagnostics Bits 0 ... 5: Reserved
Bit 6: Diagnostic alarm (0 = inhibited; 1 = enabled)
Bit 7: Reserved 00
h
02 Reserved 0
03 Limit value
monitoring Bit 0: Channel 1 (0 = deactivated; 1 = activated)
Bit 1: Channel 2 (0 = deactivated; 1 = activated)
Bits 7 ... 2: Reserved 00
h
04 Interference
frequency
suppression Bit 1, 0: Channel 1
00: Deactivated
01: 60 Hz
10: 50 Hz
Bit 3, 2: Channel 2
00: Deactivated
01: 60 Hz
10: 50 Hz
Bits 7 ... 4: Reserved
00
h
05 Function channel 1 12 (12
h
): −10 ... 10 V / −27648 ... 27648
dec
34 (22
h
): −10 ... 10 V / −16384 ... 16384
dec
16 (10
h
): 0 ... 10 V / 0 ... 27648
dec
32 (20
h
): 0 ... 10 V / 0 ... 16384
dec
255 (FF
h
): channel deactivated
20
h
06 Reserved 0
07 Upper limit value
channel 1 Value from the rated range; if this value is exceeded and the
limit value monitoring function is active, a process alarm is
triggered.
7FFF
h
: Limit value alarm deactivated
7FFF
h
08 Lower limit value
channel 1 Value from the rated range; if the actual value falls below this
value and the limit value monitoring function is active, a process
alarm is triggered.
8000
h
: Limit value alarm deactivated
8000
h
09 Function channel 2 12 (12
h
): −10 ... 10 V / −27648 ... 27648
dec
34 (22
h
): −10 ... 10 V / −16384 ... 16384
dec
16 (10
h
): 0 ... 10 V / 0 ... 27648
dec
32 (20
h
): 0 ... 10 V / 0 ... 16384
dec
255 (FF
h
): channel deactivated
20
h
0A Reserved 0
0B Upper limit value
channel 2 Value from the rated range; if this value is exceeded and the
limit value monitoring function is active, a process alarm is
triggered.
7FFF
h
: Limit value alarm deactivated
7FFF
h
0C Lower limit value
channel 2 Value from the rated range; if the actual value falls below this
value and the limit value monitoring function is active, a process
alarm is triggered.
8000
h
: Limit value alarm deactivated
8000
h
With the formulas listed in the following you can convert a digital value into an analog
output value and vice versa.
