Brocade Mobility RFS Controller System Reference Guide

945

53-1003099-01

15

1. Select the Statistics menu from the Web UI.

2. Select System from the navigation pane (on the left-hand side of the screen). Expand the a RF

Domain, select a controller or service platform, and select one of its connected Access Points.

3. Select DHCP and expand the menu to reveal its sub menu items.

4. Select Networks.

The DHCP Networks screen displays the following:

FIGURE 142

Access Point - DHCP Network screen

Firewall

Access Point Statistics

A firewall is a part of a computer system or network designed to block unauthorized access while
permitting authorized communications. It’s a device or set of devices configured to permit or deny
access to the controller or service platform managed network based on a defined set of rules.

Name

Displays the name of the DHCP pool.

Subnet Address

Displays the subnet addresses of the DHCP Pool.

Used Addresses

Number of addresses that have already been leased to requesting clients.

Total Addresses

Total available addresses that can be leased to requesting clients.

Refresh

Select Refresh to update the statistics counters to their latest values.
