FIGURE 63
OSPF Settings screen
5. Enable/disable OSPF and provide the following dynamic routing settings:
Enable OSPF
Select this option to enable OSPF. OSPF is disabled by default.
Router ID
Select this option to define a router ID (numeric IP address) for this OSPF
configuration. This ID must be established in every OSPF instance. If not explicitly
configured, the highest logical IP address is duplicated as the router identifier.
However, since the router identifier is not an IP address, it does not have to be a part
of any routable subnet in the network.
Auto-Cost
Select this option to specify the reference bandwidth (in Mbps) used to calculate the
OSPF interface cost if OSPF is either STUB or NSSA. The default setting is 1.
Passive Mode on All
Interfaces
When selected, all layer 3 interfaces are set as an OSPF passive interface. This
setting is disabled by default.
Passive Removed
If enabling Passive Mode on All Interfaces, use the spinner control to select VLANs (by
numeric ID) as OSPF non passive interfaces. Multiple VLANs can be added to the list.
Passive Mode
If disabling Passive Mode on All Interfaces, use the spinner control to select VLANs (by
numeric ID) as OSPF passive interfaces. Multiple VLANs can be added to the list.
