Brocade Mobility RFS Controller System Reference Guide 819
53-1003099-01
15
2. Select a Wireless Controller node from the left navigation pane.
3. Expand the Interfaces menu from the left-hand side of the UI.
4. Select Network Graph.
FIGURE 48 Wireless Controller - Interface Network Graph screen
RAID Statistics
Controller Statistics
RAID statistics are available to assist an administrator in assessing the status of the service
platform’s RAID array, including each physical drive. The information within the RAID statistics
screen is polled by the service platform from the RAID controller hardware, then forwarded to the
Mobility operating system.
NOTE
RAID controller drive arrays are available within RFS9510 series service platforms only.
For information on setting the service platform drive array configuration as well as the diagnostic
behavior of its member drives, refer to RAID Operations on page 14-713.
To view RAID statistics:
1. Select the Statistics menu from the Web UI.
2. Select a Wireless Controller node from the left navigation pane.
3. Select RAID from the left-hand side of the UI.
