Brocade Mobility RFS Controller System Reference Guide (Supporting software release 5.5.0.0 and later) User Manual
Page 564

552
Brocade Mobility RFS Controller System Reference Guide
53-1003099-01
9
FIGURE 5
RF Domain Override SSID screen
The Overrides screen is partitioned into two tabs, with the Override SSID screen displayed by
default.
3. Either select the + Add button to create a new Override SSID configuration. Highlight an
existing Sensor Server Configuration and select the Delete icon to remove it from the table.
4. Use the WLAN drop-down menu to select an existing WLAN to be supplied an override SSID.
If a WLAN configuration has not been defined, you’ll need to select the Create button and
define at least one complete WLAN configuration. For detailed information on the steps
required to create a WLAN, see
5. Enter the name of the SSID to use with this WLAN.
6. Select OK to save the changes to the Override SSID configuration, or select Reset to Revert to
the last saved configuration.
7. Select the Override VLAN tab.
The Override VLAN screen lists those WLANs available for override.
