752

Brocade Mobility RFS Controller System Reference Guide

53-1003099-01

15

13. The Traffic Statistics statistics table displays the following information for transmitted and

received packets:

14. The SMART RF Activity area displays the following:

Inventory

RF Domain Statistics

The Inventory screen displays an inventory of RF Domain member Access Points, connected
wireless clients, wireless LAN utilization and radio availability.

To display RF Domain inventory statistics:

1. Select the Statistics menu from the Web UI.

2. Select a RF Domain from under the System node on the top, left-hand side, of the screen.

3. Select Inventory from the RF Domain menu.

Total Bytes

Displays the total bytes of data transmitted and received within the Access Point RF Domain.

Total Packets

Lists the total number of data packets transmitted and received within the Access Point RF
Domain.

User Data Rate

Lists the average user data rate within the Access Point RF Domain.

Bcast/Mcast Packets

Displays the total number of broadcast/multicast packets transmitted and received within the
Access Point RF Domain.

Management Packets

This is the total number of management packets processed within the Access Point RF Domain.

Tx Dropped Packets

Lists total number of dropped data packets within the Access Point RF Domain.

Rx Errors

Displays the number of errors encountered during data transmission within the Access Point RF
Domain. The higher the error rate, the less reliable the connection or data transfer.

Time Period

Lists the time period when Smart RF calibrations or adjustments were made to compensate for
radio coverage holes or interference.

Power Changes

Displays the total number of radio transmit power changes that have been made using SMART RF
within the Access Point RF Domain.

Channel Changes

Displays the total number of radio transmit channel changes that have been made using SMART
RF within the Access Point RF Domain.

Coverage Changes

Displays the total number of radio coverage area changes that have been made using SMART RF
within the Access Point RF Domain.
