6

Brocade Mobility RFS Controller System Reference Guide

53-1003099-01

2

These icons indicate the current state of various controls in a dialog. These icons enables you to
gather the status of all the controls in a dialog. The absence of any of these icons next to a control
indicates the value in that control has not been modified from its last saved configuration.

Table Icons

Glossary of Icons Used

The following two override icons are status indicators for transactions:

Status Icons

Glossary of Icons Used

Entry Updated – Indicates a value has been modified from its last saved configuration.

Entry Update – States that an override has been applied to a device profile
configuration.

Mandatory Field – Indicates this control value is a mandatory configuration item. You
are not allowed to proceed further without providing all mandatory values in this dialog.

Error in Entry – Indicates there is an error in a supplied value. A small red popup
provides a likely cause of the error.

Table Row Overridden – Indicates a change (profile configuration override) has been
made to a table row and the change will not be implemented until saved. This icon
represents a change from this device’s profile assigned configuration.

Table Row Added – Indicates a new row has been added to a table and the change is
not implemented until saved. This icon represents a change from this device’s profile
assigned configuration.
