210 Brocade Mobility RFS Controller System Reference Guide
53-1003099-01
5
6. Select the Version tab to define the VRRP version scheme used with the configuration.
FIGURE 103 VVRP screen - Version tab
VRRP version 3 (RFC 5798) and 2 (RFC 3768) are selectable to set the router redundancy.
Version 3 supports sub-second (centisecond) VRRP failover and support services over virtual
IP. For more information on the VRRP protocol specifications (available publicly) refer to
http://www.ietf.org/rfc/rfc3768.txt (version 2) and http://www.ietf.org/rfc/rfc5798.txt
(version 3).
7. From within VRRP tab, select Add to create a new VRRP configuration or Edit to modify the
attributes of an existing VRRP configuration. If necessary, existing VRRP configurations can be
selected and permanently removed by selecting Delete.
Description Displays a description assigned to the VRRP configuration when it was either created or
modified. The description is implemented to provide additional differentiation beyond the
numerical virtual router ID.
Virtual IP Addresses Lists the virtual interface IP address used as the redundant gateway address for the virtual
route.
Interface Displays the interfaces selected on the Access Point to supply VRRP redundancy fail over
support.
Priority Lists a numerical value (from 1 - 254) used for the virtual router master election process. The
higher the numerical value, the higher the priority in the election process.
