20. Select Add to create a new manual session, Edit to modify an existing session configuration or
Delete to remove a selected manual session.
FIGURE 36
Network - L2TPv3 screen, Add T2TP Peer Configuration
21. Set the following session parameters:
Name
Lists the name assigned to each listed manual session.
Remote Session ID
Lists the remote session ID passed in the establishment of the tunnel session.
Name
Define a 31 character maximum name for this tunnel session. The session is created after a
successful tunnel connection and establishment. Each session name represents a single
data stream.
IP Address
Specify the IP address used as the tunnel source IP address. If not specified, the tunnel
source IP address is selected automatically based on the tunnel peer IP address. This
address is applicable only for initiating the tunnel. When responding to incoming tunnel
create requests, it would use the IP address received in the tunnel creation request.
IP
Set the IP address of an L2TP tunnel peer. This is the peer allowed to establish the tunnel.
Local Session ID
Set the numeric identifier for the tunnel session. This is the pseudowire ID for the session.
This pseudowire ID is sent in session establishment message to the L2TP peer.
