Brocade Mobility RFS Controller System Reference Guide

875

53-1003099-01

15

The Event History lists WIPS events triggered, then logged by the controller or service platform.

To view a WIPS event history:

1. Select the Statistics menu from the Web UI.

2. Select a Wireless Controller node from the left navigation pane.

3. Select Advanced WIPS and expand the menu to reveal its sub menu items.

4. Select Events History.

FIGURE 91

Wireless Controller - Advanced WIPS Event History screen

The Event History screen displays the following:

Sensor Server

Controller Statistics

Sensor servers allow the monitor and download of data from multiple sensors and remote
locations using Ethernet, TCP/IP or serial communication. Repeaters are available to extend the
transmission range and combine sensors with various frequencies on the same receiver.

To view the Sensor Server statistics:

1. Select the Statistics menu from the Web UI.

Event Name

Displays the WIPS event detected by the controller or service platform’s connected Access Point radios
and clients.

Device MAC

Displays the MAC address of the device initiating the WIPS event.

Event Time

Displays a timestamp of when each listed event was reported to the managing controller or service
platform.

Clear

Select Clear

to remove all the WIPS events and begin a new data collection.

Refresh

Select the Refresh button to update the screen’s statistics counters to their latest values
