Dhcp options – Brocade Mobility RFS Controller System Reference Guide (Supporting software release 5.5.0.0 and later) User Manual
Page 861

Brocade Mobility RFS Controller System Reference Guide
849
53-1003099-01
15
DHCP Options
Controllers and service platforms contain an internal Dynamic Host Configuration Protocol (DHCP)
server. The DHCP server can provide the dynamic assignment of IP addresses automatically from
existing address pools. This is a protocol that includes IP address allocation and delivery of
host-specific configuration parameters from a DHCP server to a host. Some of these parameters
include IP address, gateway and network mask.
To view network DHCP options:
1. Select the Statistics menu from the Web UI.
2. Select a Wireless Controller node from the left navigation pane.
3. Expand the Network menu from the left-hand side of the UI.
4. Select DHCP Options.
FIGURE 70
Wireless Controller - Network DHCP Options screen
MiNT IDs
Lists MiNT IDs for each listed VLAN. MiNT provides the means to secure access point profile
communications at the transport layer. Using MiNT, an access point can be configured to only
communicate with other authorized (MiNT enabled) access points of the same model.
Query Interval
Lists the IGMP query interval implemented when the querier functionality is enabled. The default value
is 60 seconds.
Version
Lists the multicast router IGMP version compatibility as either version 1, 2 or 3. The default setting is 3.
Refresh
Select the Refresh button to update the screen’s statistics counters to their latest values.
