802.11ac MCS rates are defined as follows both with and without short guard intervals (SGI):
Select OK when completed to update this WLAN’s advanced settings. Select Reset to revert the
screen back to its last saved configuration.
Configuring Auto Shutdown Settings
Wireless LAN Policy
The Auto Shutdown feature set the WLAN to shutdown when certain criteria are met. It also allows
administrators to set the operating days and hours of certain WLANs for security or bandwidth
purposes.
To configure advanced settings on a WLAN:
1. Select Configuration > Wireless LANs > Wireless LAN Policy available WLANs.
2. Select the Add button to create an additional WLAN or select Edit to modify the properties of an
existing WLAN.
3. Select Auto Shutdown.
MCS Index 20 MHz
No SGI 20 MHz With
SGI 40 MHz
No SGI 40MHz
With SGI 80 MHz
No SGI 80MHz
With SGI
0 6.5 7.2. 13.5 15 29.3 32.5
1 13 14.4 27 30 58.5 65
2 19.5 21.7 40.5 45 87.8 97.5
3 26 28.9 54 60 117 130
4 39 43.3 81 90 175.5 195
5 52 57.8 108 120 234 260
6 58.5 65 121.5 135 263.3 292.5
7 65 72.2 135 150 292.5 325
8 78 86.7 162 180 351 390
9 n/a n/a 180 200 390 433.3
