Page 859

Brocade Mobility RFS Controller System Reference Guide
847
53-1003099-01
15
2. Select a Wireless Controller node from the left navigation pane.
3. Expand the Network menu from the left-hand side of the UI.
4. Select Bridge.
FIGURE 68
Wireless Controller - Network Bridge screen
The Bridge screen displays the following:
IGMP
Internet Group Management Protocol (IGMP) is a protocol used for managing members of IP
multicast groups. The access point listens to IGMP network traffic and forwards the IGMP multicast
packets to radios on which the interested hosts are connected. On the wired side of the network,
the access point floods all the wired interfaces. This feature reduces unnecessary flooding of
multicast traffic in the network.
To view network IGMP configuration options:
Bridge Name
Displays the numeric ID of the network bridge.
MAC Address
Displays the MAC address of each listed bridge.
Interface
Displays the controller or service platform physical port interface the bridge uses to transfer packets.
Interface availability is slightly different amongst supported controller and service platform models.
VLAN
Displays the VLAN the bridge is using as a virtual interface within the controller or service platform
managed network.
Forwarding
Displays whether the bridge is forwarding packets.
Refresh
Select Refresh to update the statistics counters to the latest values.
