Chapter 6: Port Parameters
Section I: Basic Operations 98
Configuring Port Parameters
To configure the parameter settings of a port, perform the following
procedure:
1. From the Main Menu, type 1 to select Port Configuration.
The Port Configuration menu is shown in Figure 20 on page 95.
2. From the Port Configuration menu, type 1 to select Port Configuration.
The following prompt is displayed:
Enter port-list ->
3. Enter the number of the port you want to configure. You can specify
more than one port at a time. You can specify the ports individually (for
example, 5,7,22), as a range (for example, 18-23), or both (for example,
1,5,14-22).
The Port Configuration menu is shown in Figure 22.
Figure 22 Port Configuration (Port) Menu
Note
The Port Configuration menu in the figure above is for a 10/100 Mbps
twisted pair port. The menu for a fiber optic port will contain a subset
of the parameters.
Allied Telesyn Ethernet Switch AT-8524M - AT-S62
Production Switch
User: Manager 11:20:02 02-Jan-2004
Port Configuration
Configuring Port 11
0 - Port Description ..................... Port-1
1 - Status ............................... Enabled
2 - Broadcast Filter ..................... Disabled
3 - MDI/MDIX Crossover ................... Auto
4 - Negotiation .......................... Auto
7 - HOL Blocking Prevention Threshold .... 7168 cells
8 - Flow Control
9 - Back Pressure
L - Rate Limit
D - Set Default Port Configuration
F - Force Renegotiation
X - Reset Port
R - Return to Previous Menu
Enter your selection?
