AT-S62 User’s Guide
Section II: Advanced Operations 201
Configuring Egress Scheduling
This procedure explains how to select and configure a scheduling
method for Class of Service. Scheduling determines the order in which
the ports handle packets in their egress queues. For an explanation of
the two scheduling methods, refer to Scheduling on page 194.
Scheduling is set at the switch level. You cannot set this on a per-port
basis.
1. From the Main Menu, type 7 to select Security and Services.
The Security and Services menu is shown in Figure 55 on page 196.
2. From the Security and Services menu, type 3 to select Class of Service
(CoS).
The Class of Service (CoS) menu is shown in Figure 56 on page 197.
3. From the Class of Service (CoS) menu, type 3 to select Configure
Egress Scheduling.
The Configure Egress Scheduling menu is shown in Figure 59.
Figure 59 Configure Egress Scheduling Menu
4. Type 1 to toggle Scheduling Mode between its two possible settings.
The default setting is Strict Priority.
If you select Strict Priority, skip the next step. Options 2 through 5 in
the menu do not apply to Strict Priority scheduling.
5. If you select Weighted Round Robin Priority as the scheduling
method, select menu options 2 through 5 and specify the maximum
number of packets you want a port to transmit from each queue
before it moves to the next queue. The range is 0 to 255. For an
example, refer to Table 10 on page 195. The default value of 1 for each
queue gives all egress queues the same weight.
6. Return to the Main Menu and type S to select Save Configuration
Changes.
Allied Telesyn Ethernet Switch AT-8524M - AT-S62
Production Server
User: Manager 11:20:02 02-Jan-2004
Configure Egress Scheduling
1 - Scheduling Mode ............ Strict Priority
2 - Queue 0 Weight ............. 0
3 - Queue 1 Weight ............. 0
4 - Queue 2 Weight ............. 0
5 - Queue 3 Weight ............. 0
R - Return to Previous Menu
Enter your selection?
