Chapter 22: Multiple VLAN Modes
Section V: Virtual LANs 452
Displaying VLAN Information
To view the VLANs on the switch while the unit is operating in Multiple
VLAN mode, perform the following procedure:
1. From the Main Menu, type 2 to select VLAN Configuration.
The VLAN Configuration menu is shown in Figure 125 on page 400.
2. From the VLAN Configuration menu, type 6 to select Show VLANs.
An example of the Show VLANs menu is shown in Figure 148.
Figure 148 Show VLANs Menu, Multiple VLANS
The menu contains the following columns of information:
VID - The VLAN ID.
VLAN Name - The name of the VLAN.
Untagged (U) / Tagged (T) - The untagged and tagged ports that are
part of the VLAN.
Allied Telesyn Ethernet Switch AT-8524M - AT-S62
Production Switch
Show VLANs
User: Manager 11:20:02 02-Jan-2004
VID VLAN Name Untagged (U) / Tagged (T)
----------------------------------------------------------------
1 Client_VLAN_1 U: 1, 15
T:
2 Client_VLAN_2 U: 2, 15
T:
3 Client_VLAN_3 U: 3, 15
T:
4 Client_VLAN_4 U: 4, 15
T:
5 Client_VLAN_5 U: 5, 15
T:
6 Client_VLAN_6 U: 6, 15
T:
7 Client_VLAN_5 U: 7, 15
T:
8 Client_VLAN_6 U: 8, 15
T:
N - Next Page
U - Update Display
R - Return to Previous Menu
Enter your selection?
