Chapter 12: File Downloads and Uploads
Section II: Advanced Operations 162
of an enhanced stack. You cannot use TFTP on a slave switch,
since that type of switch typically does not have an IP address.
Instead, you would need to perform the download from a local
management session of the switch using Xmodem or,
alternatively switch to switch, as explained in Downloading an
AT-S62 Image File Switch to Switch on page 167.
The following procedures assume that you have already obtained the
new software from Allied Telesyn and stored it on the management
workstation from which you will be performing the procedure, or on the
TFTP server.
Downloading
the AT-S62
Image from a
Local
Management
Session
To download a new software image onto a switch from a local
management session using Xmodem or TFTP, perform the following
procedure:
1. Establish a local management session on the switch where you intend
to download the new management software.
2. From the Main Menu, type 5 to select System Administration.
The System Administration menu is shown in Figure 7 on page 59.
3. From the System Administration menu, type 9 to select System
Utilities.
The System Utilities menu is shown in Figure 9 on page 64.
4. For the System Utilities menu, type 2 to select Downloads and
Uploads.
The Downloads and Uploads menu is shown in Figure 44.
Figure 44 Downloads and Uploads Menu
Allied Telesyn Ethernet Switch AT-8524M - AT-S62
Production Switch
User: Manager 11:20:02 02-Jan-2004
Downloads and Uploads
1 - Download Application Image/BootLoader
2 - Upload Application Image/BootLoader
3 - Download a file
4 - Upload a file
R - Return to Previous Menu
Enter your selection?
