Chapter 14: Quality of Service
Section II: Advanced Operations 198
The Configure Port COS Priorities menu is shown in Figure 57.
Figure 57 Configure Port COS Priorities Menu
Menu option 1 cannot be changed.
5. Type 2 to select Priority (0 - 7). The following prompt is displayed:
Enter new value -> [0 to 7]
6. Enter a value from 1 to 7 that corresponds to the egress queue where
you want all untagged frames received on the port to be stored. For
example, if you want all ingress untagged packets received on the
port stored in egress queue Q2, enter 4 or 5. The default is 0, which
corresponds to Q0. (If you perform Step 6 and override the priority
level in tagged packets, this queue will also be used to store all tagged
packets.) The values are listed in Table 11.
7. If you are configuring a tagged port and you want the switch to
ignore the priority tag in ingress tagged frames, type 3 to select
Override Priority and type Y.
All ingress tagged frames are directed to the queue specified in Step
6.
Table 11 Default Mappings of Priority Levels to Priority Queues
Value Egress Queue
0 or 1 Q0
2 or 3 Q1
4 or 5 Q2
6 or 7 Q3
Allied Telesyn Ethernet Switch AT-8524M - AT-S62
Production Server
User: Manager 11:20:02 02-Jan-2004
Configure Port COS Priorities
1 - Port Number ................... 1
2 - Priority (0-7) 0=Low 7=High ... 0
3 - Override Priority (Y/N) ....... N
C - Configure COS Priorities
R - Return to Previous Menu
Enter your selection?
