AT-S62 User’s Guide
Section IV: Spanning Tree Protocols 345
The Configure STP Port Settings menu is shown in Figure 104.
Figure 104 Configure STP Port Settings Menu
6. Adjust the settings as desired. The parameters are described below.
1 - Port Priority
This parameter is used as a tie breaker when two or more ports are
determined to have equal costs to the root bridge. The range is 0
to 240 in increments of 16. The default value is 8 (priority value
128). For a list of the increments, refer to Table 17, Port Priority
Value Increments on page 334.
2 - Port Cost
The spanning tree algorithm uses the cost parameter to decide
which port provides the lowest cost path to the root bridge for
that LAN. The range is 0 to 65,535. The default setting is Automatic
Update, which sets port cost depending on the speed of the port.
For the default values used by Automatic Update, refer Table 13
on page 332 and Table 14 on page 333.
All changes are immediately activated on the switch.
7. After making changes, type R until you return to the Main Menu. Then
type S to select Save Configuration Changes.
Allied Telesyn Ethernet Switch AT-8524M - AT-S62
Production Switch
User: Manager 11:20:02 02-Jan-2004
Configure STP Port Settings
Configuring Ports 4-4
1 - Port Priority ..... 128
2 - Port Cost ......... Automatic-Update
R - Return to Previous Menu
Enter your selection?
