AT-S62 User’s Guide
Section II: Advanced Operations 211
Displaying a List of Multicast Routers
A multicast router is a router that is receiving multicast packets from a
multicast application and transmitting the packets to host nodes. You
can use the AT-S62 software to display a list of the multicast routers that
are connected to the switch.
To display a list of the multicast routers, perform the following
procedure:
1. From the Main Menu, type 6 to select Advanced Configuration.
The Advanced Configuration menu is shown in Figure 61 on page
206.
2. From the Advanced Configuration menu, type 1 to select IGMP
Snooping Configuration.
The IGMP Snooping Configuration menu is shown in Figure 62 on
page 206.
3. From the IGMP Snooping Configuration menu, type 7 to select View
Multicast Routers List. The View Multicast Routers List menu is shown
in Figure 64.
Figure 64 View Multicast Routers List Menu
The information in this menu is for viewing purposes only. The
columns are defined below:
VLAN
The VID of the VLAN in which the port is an untagged member.
Port
The port on the switch where the multicast router is connected. If the
switch learned the router on a port trunk, the trunk ID number, not
the port number, is displayed.
Router IP
The IP address of the multicast router.
Allied Telesyn Ethernet Switch AT-8524M - AT-S62
Production Switch
User: Manager 11:20:02 02-Jan-2004
View Multicast Routers List
VLAN Port/TrunkID RouterIP
------------------------------------------------
U - Update Display
R - Return to Previous Menu
Enter your selection?
