AT-S62 User’s Guide
Section VIII: Web Browser Management 783
Displaying MAC Address Security Levels
To display the MAC address security level of a port, perform the
following procedure:
1. From the Home page, select Monitoring.
2. Select Layer 2.
The Layer 2 page is displayed with the MAC Address tab selected
by default, as shown in Figure 208 on page 622.
3. Select the Port Security tab.
The Port Security tab is shown in Figure 281.
Figure 281 Port Security Tab (Monitoring)
4. Click the port whose port security level you want to view. A selected
port turns white. You can select more than one port at a time.
5. Click View.
The security information for the selected ports is displayed in the
Security for Port(s) page. An example is shown in Figure 282.
Figure 282 Security for Port(s) Tab
