AT-S62 User’s Guide
Section IV: Spanning Tree Protocols 347
Configuring RSTP
This section contains the following procedures:
❑ Configuring RSTP Bridge Settings, next
❑ Configuring RSTP Port Settings on page 349
Configuring
RSTP Bridge
Settings
This section contains the procedure for configuring a bridge’s RSTP
settings.
Caution
The default RSTP parameters are adequate for most networks.
Changing them without prior experience and an understanding of
how RSTP works might have a negative effect on your network. You
should consult the IEEE 802.1w standard before changing any of the
RSTP parameters.
To configure the RSTP bridge settings, do the following
1. From the Spanning Tree Configuration menu, type 3 to select
Configure Active Protocol.
The RSTP Menu is shown in Figure 106.
Figure 106 RSTP Menu
Allied Telesyn Ethernet Switch AT-8524M - AT-8024
Production Switch
User: Manager 11:20:02 02-Jan-2004
RSTP Menu
1 - Force Version .......... RSTP
2 - Bridge Priority ........ 32768 (In multiples of 4096: 8)
3 - Bridge Hello Time ...... 2
4 - Bridge Forwarding ...... 15
5 - Bridge Max Age ......... 20
6 - Bridge Identifier ...... 00:30:84:00:00:00
P - RSTP Port Parameters
D - Reset RSTP to Defaults
R - Return to Previous Menu
Enter your selection?
