AT-S62 User’s Guide
Section VII: Management Security 561
3 - RADIUS Server 1 Configuration
4 - RADIUS Server 1 Configuration
5 - RADIUS Server 1 Configuration
Use these parameters to specify the IP addresses of up to
three network servers containing the RADIUS server software.
Selecting one of the options displays the RADIUS Server
Configuration menu, shown in Figure 184.
Figure 184 RADIUS Server Configuration
The options are described below:
1 - Server IP Address
Use this option to specify the IP address of the RADIUS server.
2 - Server Authentication UDP Port
Use this option to specify the UDP port of the RADIUS
protocol.
3 - Server Encryption Key
Use this option to specify the encryption key for the RADIUS
server.
c. After you have finished configuring the parameters in the RADIUS
Client Configuration menu, type R to return to the Authentication
Menu, shown in Figure 181 on page 557.
Note
Steps d. and e. should only be performed to support new manager
accounts. If you are configuring the RADIUS client software solely for
the 802.1x port-based access control feature described in Chapter
24 on page 463, leave menu option 1 - Server-based Authentication
as disabled and skip ahead to step f.
Allied Telesyn Ethernet Switch AT-8524M - AT-S62
Production Switch
User: Manager 11:20:02 02-Jan-2004
RADIUS Server 1 Configuration
1 - Server IP Address ................. 0.0.0.0
2 - Server Authentication UDP Port .... 1812
3 - Server Encryption Key .............
R - Return to Previous Menu
Enter your selection?
