AT-S62 User’s Guide
Section V: Virtual LANs 401
The Configure VLANs menu is shown in Figure 126.
Figure 126 Configure VLANs Menu
3. From the Configure VLANs menu, type 1 to select Create VLAN.
The Create VLAN menu is shown in Figure 127.
Figure 127 Create VLAN Menu
4. Type 1 to select VLAN Name and enter a name for the new VLAN.
The name can be from one to fifteen alphanumeric characters in
length. The name should reflect the function of the nodes that will be
a part of the VLAN (for example, Sales or Accounting). The name
cannot contain spaces or special characters, such as asterisks (*) or
exclamation points (!).
If the VLAN will be unique in your network, then the name should be
unique as well. If the VLAN will be part of a larger VLAN that spans
multiple switches, then the name for the VLAN should be the same on
each switch where nodes of the VLAN are connected.
Allied Telesyn Ethernet Switch AT-8524M - AT-S62
Production Switch
User: Manager 11:20:02 02-Jan-2004
Configure VLANs
1 - Create VLAN
2 - Modify VLAN
3 - Delete VLAN
4 - Reset to Default VLAN
R - Return to Previous Menu
Enter your selection?
Allied Telesyn Ethernet Switch AT-8524M - AT-S62
Production Switch
User: Manager 11:20:02 02-Jan-2004
Create VLAN
1 - VLAN Name ............
2 - VLAN ID (VID) ........ 2
3 - Tagged Ports .........
4 - Untagged Ports .......
C - Create VLAN
R - Return to Previous Menu
Enter your selection?
