AT-S62 User’s Guide
Section I: Basic Operations 95
Displaying Port Status
To display the current status and settings of the ports on the switch,
perform the following procedure:
1. From the Main Menu, type 1 to select Port Configuration.
The Port Configuration menu is shown in Figure 20.
Figure 20 Port Configuration Menu
2. From the Port Configuration Menu, type 2 to select Port Status.
An example of the Port Status menu is shown in Figure 21.
Figure 21 Port Status Menu
Allied Telesyn Ethernet Switch AT-8524M - AT-S62
Production Switch
User: Manager 11:20:02 02-Jan-2004
Port Configuration
1 - Port Configuration
2 - Port Status
3 - Port Statistics
4 - Port Trunking
5 - Port Security
6 - Port Mirroring
R - Return to Previous Menu
Enter your selection?
Allied Telesyn Ethernet Switch AT-8524M - AT-S62
Production Switch
User: Manager 11:20:02 02-Jan-2004
Port Status
Port Link Neg MDIO Speed Duplex PVID Flow Ctl
---------------------------------------------------------
1
Up Auto Auto 0010 Half 0012 Disabled
2 Up Auto Auto 0100 Full 0012 Disabled
3 Up Auto Auto 0100 Full 0012 Disabled
4 Up Auto Auto 0100 Full 0023 Disabled
5 Up Auto Auto 0010 Half 0012 Disabled
6 Up Auto Auto 0100 Full 0011 Disabled
7 Up Auto Auto 0100 Full 0011 Disabled
8 Up Auto Auto 0010 Half 0011 Disabled
N - Next Page
U - Update Display
R - Return to Previous Menu
Enter your selection?
