AT-S62 User’s Guide
Section I: Basic Operations 133
The Modify Trunk menu is displayed. The menu displays the
operating specifications of the selected trunk. An example is shown in
Figure 37.
Figure 37 Modify Trunk Menu
Note
You cannot change a trunk’s ID number.
5. To modify a port trunk’s name, type 2 to select Trunk Name and, when
prompted, enter the new name for the trunk. The name can be up to
fifteen alphanumeric characters. No spaces or special characters, such
as asterisks and exclamation points, are allowed. Each trunk must
have a unique name.
6. To change the trunk’s load distribution method, type 3 to toggle the
selection through the following possible settings.
❑ SRC MAC - Source MAC address
❑ DST MAC - Destination MAC address
❑ SRC/DST MAC - Source address /destination MAC address
❑ SRC IP - Source IP address trunking
❑ DST IP - Destination IP address trunking
❑ SRC/DST IP - Source address /destination IP address
For background information on these selections, refer to Load
Distribution Methods on page 123.
Allied Telesyn Ethernet Switch AT-8524M - AT-S62
Production Switch
User: Manager 11:20:02 02-Jan-2004
Modify Trunk
1 - Trunk ID ......... 2
2 - Trunk Name ....... Server11
3 - Trunk Method ..... SRC/DST MAC
4 - Trunk Ports ...... 12-16
M - Modify Trunk
R - Return to Previous Menu
Enter your selection?
