Chapter 21: GARP VLAN Registration Protocol
Section V: Virtual LANs 438
Figure 143 GVRP Counters Menu (page 2)
The GVRP counters in the menus are defined in Table 20.
Allied Telesyn Ethernet Switch AT-8524M - AT-S62
Production Switch
User: Manager 11:20:02 02-Jan-2004
GVRP Counters
Receive: Transmit:
--------
---------
GARP Messages:
---------------
LeaveAll
7 LeaveAll 77
JoinEmpty 0 JoinEmpty 58
JoinIn 68 JoinIn 285
LeaveEmpty 0 LeaveEmpty 1
LeaveIn 0 LeaveIn 0
Empty 5 Empty 21
Bad Message 0
Bad Attribute 0
P - Previous Page
U - Updated Display
R - Return to Previous Menu
Enter your selection?
Table 20 GVRP Counters
Parameter Meaning
Receive: Total GARP
Packets Total number of GARP PDUs received by this
GARP application.
Transmit: Total GARP
Packets Total number of GARP PDUs transmitted by
this GARP application.
Receive: Invalid GARP
Packets Number of invalid GARP PDUs received by
this GARP application.
Receive Discarded:
GARP Disabled Number of received GARP PDUs discarded
because the GARP application was disabled.
Transmit Discarded:
GARP Disabled Number of GARP PDUs discarded because
the GARP application was disabled. This
counter is incremented when ports are
added to or deleted from the GARP
application arising from port movements in
the underlying VLAN or STP.
