AT-S62 User’s Guide

Section VI: Port Security

459

5. Press 1 to change the port security on your specified port list.

The following prompt appears:

Enter new mode (A-Automatic, L-Limited, S-Secured,
K-locKed):

6. Select the desired security level. For definitions of the security levels,

refer to MAC Address Security Overview on page 455.

If you select Automatic, which disables port security on the port,
return to the Main Menu to save your change.

If you selected Limited, several new menu options are added to
the Configure Port Security menu, as shown in Figure 151.

Figure 151 Configure Port Security Menu #2

Note

If you selected Limited, go to the next step. If you selected the
Secured or Locked mode, no further steps are required. You can
repeat this procedure to configure other ports or go to step 10 to
save your changes.

7. If you selected the Limited security mode for the port, do the

following to specify the maximum number of dynamic MAC
addresses you want the port to be able to learn:

a. Type 2 to select Threshold.

The following prompt appears:

Enter port security threshold: [1 to 256] -> 100

b. Enter the maximum number of dynamic MAC addresses you want

the port to be able to learn. The range is 1 to 256. The default is
100.

Allied Telesyn Ethernet Switch AT-8524M - AT-S62

Production Switch

User: Manager

11:20:02 02-Jan-2004

Configure Port Security

Configuring Port Security 4

1 - Security Mode ..................... Limited
2 - Threshold ......................... 100
3 - Intruder Action ................... Discard
4 - Port Participating ................ No

D - Set Default Port Security
R - Return to Previous Menu

Enter your selection?
