AT-S62 User’s Guide
Section V: Virtual LANs 411
Deleting a VLAN
This procedure deletes port-based and tagged VLANs from the switch.
All untagged ports in a deleted VLAN are returned to the Default_VLAN.
Note
To delete a VLAN, you need to know its VID. To view VLAN VIDs, refer
to Displaying VLANs on page 410.
To delete a VLAN, perform the following procedure:
1. From the Main Menu, type 2 to select VLAN Configuration.
The VLAN Configuration menu is shown in Figure 125 on page 400.
2. From the VLAN Configuration menu, type 4 to select Configure
VLANs.
The Configure VLANs menu is shown in Figure 126 on page 401.
Note
If option “4 - Configure VLANs” is not displayed in the menu, the
switch is running a multiple VLAN mode. To change a switch’s VLAN
mode, refer to Selecting a VLAN Mode on page 451.
3. From the Configure VLANs menu, type 3 to select Delete VLAN.
The Delete VLAN menu is shown in Figure 131.
Figure 131 Delete VLAN Menu
4. Type 1 to select VLAN ID (VID).
The following prompt is displayed:
Enter new value -> [2 to 4094] ->
5. Enter the VID of the VLAN you want to delete. You can specify only
one VID at a time.
Allied Telesyn Ethernet Switch AT-8524M - AT-S62
Production Switch
User: Manager 11:20:02 02-Jan-2004
Delete VLAN
1 - VLAN ID (VID) ........
R - Return to Previous Menu
Enter your selection?
