Chapter 41: Quality of Service
Section VIII: Web Browser Management 664
Displaying the CoS Settings
To display the CoS settings, do the following:
1. From the Home page, select Monitoring.
The Monitoring System page is displayed with the General tab
selected by default, as shown in Figure 195 on page 590
2. From the Monitoring menu, select the QoS option.
The QoS page is displayed with the CoS tab selected by default, as
shown in Figure 224.
Figure 224 CoS Tab (Monitoring)
3. Click the port where you want to view the settings. You can select
more than one port at a time. A selected port turns white. (To deselect
a port, click it again.)
4. Click View. The CoS Setting for Port page is shown in Figure 225.
Figure 225 CoS Setting for Port Page
