Chapter 21: GARP VLAN Registration Protocol
Section V: Virtual LANs 442
GIP Connected
Ports Ring
Option 3 - Display GIP Connected Ports Ring in the Other GARP Port
Parameters displays the GIP Connected Ports Ring Menu as shown in
Figure 145.
Figure 145 GIP Connected Ports Ring Menu
The information in the menu is defined in Table 22. This information is
for viewing purposes only.
Allied Telesyn Ethernet Switch AT-8524M - AT-S62
Production Switch
User: Manager 11:20:02 02-Jan-2004
GIP Connected Ports Ring
GARP Application: GVRP
GIP Context ID: 0, STP ID: 0
-------------------------------------------------------------
2 -> 8 -> 4
U - Update Display
R - Return to Previous Menu
Enter your selection?
Table 22 GIP Connected Ports Ring Parameters
Parameter Meaning
GARP Application Identifies the GARP application, that is,
“GVRP.”
GIP Context ID A number assigned to the instance for the
GIP context.
STP ID Present if the GARP application is GVRP;
identifies the spanning tree instance
associated with the GIP context.
Connected Ring Ring of connected ports. Only ports
presently in the STP Forwarding state are
eligible for membership to the GIP
connected ring. If no ports exist in the GIP
connected ring, “No ports are connected” is
displayed. If the GARP application has no
ports, “No ports have been assigned” is
displayed.
