AT-S62 User’s Guide
Section VIII: Web Browser Management 743
Enabling or Disabling Spanning Tree
To enable or disable spanning tree on the switch, do the following:
1. From the Home page, select Configuration.
The System page is displayed with the General tab selected by
default, as shown in Figure 194 on page 586.
2. From the Configuration menu, select Layer 2.
The Layer 2 page is displayed with the MAC Address tab shown by
default, as shown in Figure 208 on page 622.
3. Select the Spanning Tree tab.
The Spanning Tree tab is shown in Figure 265.
Figure 265 Spanning Tree Tab (Configuration)
4. To select an active spanning tree for the switch, click either STP,
RSTP, or MSTP for the Active Protocol Version parameter. Only one
protocol can be active on the switch at a time. The default is RSTP.
5. Click Apply.
6. To enable or disable spanning tree, click the Enable Spanning Tree
check box. A check indicates that the feature is enabled while no
check indicates that the feature is disabled. The default is disabled.
Note
Do not enable spanning tree on the switch until after you have
selected an activate spanning tree protocol and configured the
settings.
