Chapter 21: GARP VLAN Registration Protocol
Section V: Virtual LANs 436
Displaying GVRP Parameters and Statistics
To display GVRP counters, database, state machine, and GIP connected
ports ring, perform the following procedure:
1. From the Main Menu, type 2 to select VLAN Configuration.
The VLAN Configuration menu is shown in Figure 125 on page
400.
2. From the VLAN Configuration menu, type 8 to select Configure GARP-
GVRP.
The GARP-GVRP Menu is shown in Figure 137 on page 430.
3. From the GARP-GVRP Menu, select O - Other GVRP Parameters Menu.
The Other GARP Port Parameters Menu is shown in Figure 141.
Figure 141 Other GARP Port Parameters Menu
Each option is reviewed in a separate subsection below.
Allied Telesyn Ethernet Switch AT-8524M - AT-S62
Production Switch
User: Manager 11:20:02 02-Jan-2004
Other GARP Port Parameters
1 - Display GVRP Counters
2 - Display GVRP Database
3 - Display GIP Connected Ports Ring
4 - Display GVRP State Machine
R - Return to Previous Menu
Enter your selection?
