Allied Telesis AT-S62 - Manual (Page 816)

Chapter 53: Management Access Control List
Section VIII: Web Browser Management 816
Creating a Management ACL
To create a Management ACL, perform the following procedure:
Note
Activating this feature without specifying any ACEs will prohibit you
from managing the device remotely.
1. From the Home Page, select Configuration.
The System page is displayed with the General tab selected by
default, as shown in Figure 194 on page 586.
2. Click Security.
3. Select the Mgmt ACL tab.
The Mgmt ACL tab is shown in Figure 302.
Figure 302 Mgmt ACL Tab (Configuration)
ACEs already existing in the Management ACL are listed in the
middle section of the tab.
4. To add a new ACE, in the Mgmt. ACL IP Address field enter the IP
address of a specific management workstation (for example,
149.11.11.11) or a subnet. You must enter an IP address. If you enter
an IP address of a specific management node, then that node will
