Chapter 10: Ethernet Statistics
Section I: Basic Operations 142
Displaying Port Statistics
To display Ethernet port statistics, perform the following procedure:
1. From the Main Menu, type 1 to select Port Configuration.
2. From the Port Configuration menu, type 3 to select Port Statistics.
The Port Statistics menu is shown in Figure 40.
Figure 40 Port Statistics Menu
3. From the Port Statistics menu, type 1 to select Display Port Statistics.
This prompt is displayed:
Enter port-list:
4. Enter the port whose statistics you want to view. You can specify
more than one port at a time.
A menu is displayed containing the statistics for each port. The
information in this menu is for viewing purposes only. The statistics
are defined below:
Bytes Received
Number of bytes received on the port.
Bytes Sent
Number of bytes transmitted from the port.
Frames Received
Number of frames received on the port.
Frames Sent
Number of frames transmitted from the port.
Broadcast Frames Received
Number of broadcast frames received on the port.
Broadcast Frames Sent
Number of broadcast frames transmitted from the port.
Allied Telesyn Ethernet Switch AT-8524M - AT-S62
Production Switch
User: Manager 11:20:02 02-Jan-2004
Port Statistics
1 - Display Port Statistics
3 - Clear Port Statistics
R - Return to Previous Menu
Enter your selection?
