Chapter 46: Virtual LANs
Section VIII: Web Browser Management 766
Modifying a Port-Based or Tagged VLAN
This procedure explains how to add or remove ports from a VLAN. When
modifying a VLAN, note the following:
❑ You cannot change the VID of a VLAN.
❑ You cannot change the name of a VLAN from a web browser
management session; you can from a local or Telnet session.
❑ You cannot modify VLANs when the switch is operating in one of
the multiple VLAN modes.
To modify a VLAN, perform the following procedure:
1. From the Home Page, select Configuration.
The System page is displayed with the General tab selected by
default, as shown in Figure 194 on page 586.
2. From the Configuration menu, select Layer 2.
The Layer 2 page is displayed with the MAC Address tab selected
by default, as shown in Figure 208 on page 622.
3. Select the VLAN tab.
The VLAN tab is shown in Figure 275 on page 762.
4. Click the button next to the name of the VLAN you want to modify.
5. Click Modify.
The Modify VLAN window for the VLAN is displayed.
6. To add or remove ports from the VLAN, click on the appropriate ports
in the switch image.
Clicking repeatedly on a port toggles it through the following
possible settings:
Untagged port
Tagged port
Port not a member of the VLAN
