Allied Telesis AT-S62 - Manual (Page 776)

Chapter 47: GARP VLAN Registration Protocol
Section VIII: Web Browser Management 776
Configuring GVRP
To configure the GVRP parameters, perform the following procedure:
1. From the Home Page, select Configuration.
The System page is displayed with the General tab selected by
default, as shown in Figure 194 on page 586
2. From the Configuration menu, select the Layer 2 option.
3. Select the GVRP tab.
The GVRP tab is shown in Figure 278.
Figure 278 GVRP Tab (Configuring)
The GVRP tab is not shown if MSTP is enabled on the switch.
The Default button returns all GVRP parameter settings to their
default values.
4. Configure the following parameters:
Enable GVRP
Click in this box to enable GVRP.
Leave Time
Sets the duration of the Leave Period timer. The range is from 30
to180 centiseconds and the default is 60.
