Chapter 9: Port Mirroring
Section I: Basic Operations 138
Creating a Port Mirror
To create a port mirror, perform the following procedure:
1. From the Main Menu, type 1 to select Port Configuration.
The Port Configuration menu is shown in Figure 20 on page 95.
2. From the Port Configuration menu, type 6 to select Port Mirroring.
The Port Mirroring menu is shown in Figure 38.
Figure 38 Port Mirroring Menu #1
3. Type 1 to select Enable/Disable.
The following prompt is displayed.
Enter Enable(E)/Disable(D):
4. Type E to enable the feature.
New options are added to the Port Mirroring menu, as shown in
Figure 39.
Figure 39 Port Mirroring Menu #2
Allied Telesyn Ethernet Switch AT-8524M - AT-S62
Production Switch
User: Manager 11:20:02 02-Jan-2004
Port Mirroring
1 - Enable/Disable .................... Disabled
R - Return to Previous Menu
Enter your selection?
Allied Telesyn Ethernet Switch AT-8524M - AT-S62
Production Switch
User: Manager 11:20:02 02-Jan-2004
Port Mirroring
1 - Enable/Disable ...................... Enabled
2 - Mirror-To (Destination) Port ........ None
3 - Ingress (Rx) Mirror (Source) Ports .. None
4 - Egress (Tx) Mirror (Source) Ports ... None
R - Return to Previous Menu
Enter your selection?
