AT-S62 User’s Guide
Section VIII: Web Browser Management 611
The Port Configuration page is shown Figure 204.
Figure 204 Port Configuration Page
Note
The Port Configuration page in the figure above is for a 10/100 Mbps
twisted pair port. The page for a fiber optic port on an optional
expansion module will contain a subset of the parameters.
If you are configuring multiple ports and the ports have different
settings, the Port Configuration menu displays the settings of the
lowest numbered port. Once you have configured the settings of
the port, all of its settings are copied to the other selected ports.
The Defaults button returns the port settings to the default
values, which are listed in Appendix A, AT-S62 Default Settings on
page 820.
6. Adjust the port parameters as needed.
The parameters are described below.
Port Name
You use this selection to assign a name to a port. The name can be
from one to fifteen alphanumeric characters. Spaces are allowed,
but you should not use special characters, such as asterisks or
exclamation points. (You cannot assign a name when you are
configuring more than one port.)
Speed and Duplex
You use this selection to configure a port for Auto-Negotiation or
to manually set a port’s speed and duplex mode.
If you select Auto for Auto-Negotiation, which is the default
setting, the switch will set both speed and duplex mode for the
port automatically.
