744 ACL Commands
FILE LOCATION: C:\Users\gina\Desktop\Checkout_new\CLI Folders\Dell Plasma-ARC
2+3\new_system_mifs_ARC2_latest\ACL.fm
D E L L C O N F ID E N T IA L – P R E L IM I N A RY 4 / 3 /1 4 - FO R P R O O F O N LY
• An ACL cannot be bound to a port that is already bound to an ACL,
without first removing the current ACL. Both ACLs must be mentioned at
the same time in this command.
• When the user binds ACL to an interface, TCAM resources will be
consumed. One TCAM rule for each MAC or IP ACE and two TCAM
rules for each IPv6 ACE.The TCAM consumption is always even number,
so in case of odd number of rules the consumption will be increased by 1.
Example
console(config)# mac access-list extended server-acl
console(config-mac-al)# permit 00:00:00:00:00:01
00:00:00:00:00:ff any
console(config-mac-al)# exit
console(config)# interface gi0/1
console(config-if)# service-acl input server-acl default-
action deny-any
service-acl input block
Use the service-acl input Interface Configuration mode commands to discard
packets that are classified to specific protocols. Use the no form of those
commands to disable discarding of the packets.
Syntax
service-acl input protocol1 [protocol2 … protocol6 ]
no service-acl input
Parameters
protocol—Specifies a protocol to filter. Available values are: blockcdp,
blockvtp, blockdtp, blockudld, blockpagp, blocksstp, and blockall.
Default Configuration
No protocol is defined.
