Address Table Commands

421

FILE LOCATION: C:\Users\gina\Desktop\Checkout_new\CLI Folders\Dell Plasma-ARC

2+3\new_system_mifs_ARC2_latest\Address_Table.fm

D E LL CO N F I D E N T IA L – P R E L I M I N A RY 4 / 3 / 14 - F O R PR O O F O N LY

For each Forwarding Data Base (FDB) mode, use different CLI commands to

configure static entries for IPv6 Multicast addresses in the FDB, as described

in the following table:

The following table describes the actual data that is written to the Forwarding

Data Base (FDB) as a function of the MLD version that is used in the

network:

(*) Note that (*,G) cannot be written to the FDB if the mode is ip-src-group.

In that case, no new FDB entry is created, but the port is added to the (S,G)

entries (if they exist) that belong to the requested group.
If an application on the device requests (*,G), the operating FDB mode is

changed to ip-group.
You can execute the command before the VLAN is created.

Example

The following example configures the Multicast bridging mode as an ip-

group on VLAN 2.

console(config)# interface vlan 2

console(config-if)# bridge multicast ipv6 mode

ip-group

FDB Mode

CLI Commands

mac-group

bridge multicast address

ipv6-group

ipv6-src-group

bridge multicast ipv6 source

FDB mode

MLD version 1

MLD version 2

mac-group

MAC group address

ipv6-group

IPv6 group address

ipv6-src-group

(*)

IPv6 source and group addresses
