464 LLDP Commands
FILE LOCATION: C:\Users\gina\Desktop\Checkout_new\CLI Folders\Dell Plasma-ARC
2+3\new_system_mifs_ARC2_latest\LLDP.fm
D E L L C O N F ID E N T IA L – P R E L IM I N A RY 4 / 3 /1 4 - FO R P R O O F O N LY
lldp optional-tlv 802.1 ppvid add ppvid - The Protocol Port VLAN ID
(PPVID) is advertised. The PPVID is the PVID that is used depending on the
packet’s protocol.
lldp optional-tlv 802.1 ppvid
remove ppvid - The PPVID is not advertised.
lldp optional-tlv 802.1 vlan add vlan-id - This vlan-id is advertised.
lldp optional-tlv 802.1 vlan remove vlan-id - This vlan-id is not advertised.
lldp optional-tlv 802.1 protocol add {stp | rstp | mstp | pause | 802.1x |
lacp | gvrp} - The protocols selected are advertised.
lldp optional-tlv 802.1 protocol remove {stp | rstp | mstp | pause | 802.1x |
lacp | gvrp} - The protocols selected are not advertised.
Parameters
• lldp optional-tlv 802.1 pvid {enable | disable} —Advertises or stop
advertize the PVID of the port.
• lldp optional-tlv 802.1 ppvid add/remove ppvid —Adds/removes PPVID
for advertising. (range: 0–4094). PPVID = 0 indicates that the port is not
capable of supporting port and protocol VLANs and/or the port is not
enabled with any protocol VLANs.
• add/remove vlan-id —Adds/removes VLAN for advertising (range: 0–4094).
• add/remove {stp | rstp | mstp | pause | 802.1x | lacp | gvrp} —Add
specifies to advertise the specified protocols; remove specifies not to
advertise the specified protocol.
Default Configuration
The following 802.1 TLV is transmitted:
Command Mode
Interface (Ethernet) Configuration mode
Example
console(config)# lldp optional-tlv 802.1 protocol add stp
