LLDP Commands 479
FILE LOCATION: C:\Users\gina\Desktop\Checkout_new\CLI Folders\Dell Plasma-ARC
2+3\new_system_mifs_ARC2_latest\LLDP.fm
D E LL CO N F I D E N T IA L – P R E L I M I N A RY 4 / 3 / 14 - F O R PR O O F O N LY
Port Capabilities Network Policy Location Notifications Inventory
------- --------- -------------- --------- ---------- ---------
gi0/1 Yes Yes Yes Enabled Yes
Network policies:
Location:
Civic-address: 61:62:63:64:65:66
show lldp local tlvs-overloading
When an LLDP packet contains too much information for one packet, this is
called overloading. Use the show lldp local tlvs-overloading EXEC mode
command to display the status of TLVs overloading of the LLDP on all ports
or on a specific port.
Syntax
show lldp local tlvs-overloading [interface-id]
Parameters
interface-id—Specifies a port ID.
Default Configuration
If no port ID is entered, the command displays information for all ports.
Command Mode
User EXEC mode
User Guidelines
The command calculates the overloading status of the current LLDP
configuration, and not for the last LLDP packet that was sent.
Example
console# show lldp local tlvs-overloading gi0/1
TLVs Group Bytes Status
------------ ------ --------------
Mandatory 31 Transmitted
