FlexCAN
Freescale Semiconductor 25-3
25.1.2 External Signals
The FlexCAN module/CAN transceiver is composed of two signals: CANTX, which is the serial
transmitted data, and CANRX, which is the serial received data.
0x1C_0008 Prescaler Divider (PRESDIV) Control Register 2
(CANCTRL2)
Free Running Timer (TIMER)
0x1C_000C Reserved Reserved
0x1C_0010 Rx Global Mask (RXGMASK)
0x1C_0014 Rx Buffer 14 Mask (RX14MASK)
0x1C_0018 Rx Buffer 15 Mask (RX15MASK)
0x1C_0020 Error and Status (ESTAT) Interrupt Masks (IMASK)
0x1C_0024 Interrupt Flags (IFLAG) Rx Error Counter
(RXECTR)
Tx Error Counter
(TXECTR)
0x1C_0034–
0x1C_007F
Reserved Reserved
0x1C_0080–
0x1C_017F
Message Buffers 0–15
Table 25-1. FlexCAN Memory Map (continued)
IPSBAR
Offset
[31:24] [23:16] [15:8] [7:0]
