Ons are shown in, Figure 26-16, Figure 26-17 – Motorola ColdFire MCF5281 User Manual
Page 515: Figure 26-18, Clr n register bits are described in table 26-6

General Purpose I/O Module
Freescale Semiconductor
26-15
CLRn register bits are described in
.
7
6
5
4
3
2
1
0
Field
—
CLRn6
CLRn5
CLRn4
CLRn3
CLRn2
CLRn1
CLRn0
Reset
0000_0000
R/W:
R
R/W
Address
IPSBAR + 0x10_0049 (CLRQS)
Figure 26-16. Port Clear Output Data Register (7-bit)
7
6
5
4
3
2
1
0
Field
—
CLRn5
CLRn4
CLRn3
CLRn2
CLRn1
CLRn0
Reset
0000_0000
R/W:
R
R/W
Address
IPSBAR + 0x10_0048 (CLRAS), 0x10_004A (CLRSD)
Figure 26-17. Port Clear Output Data Registers (6-bit)
7
4
3
2
1
0
Field
—
CLRn3
CLRn2
CLRn1
CLRn0
Reset
0000_0000
R/W:
R
R/W
Address
IPSBAR + 0x10_004B (CLRTC), 0x10_004C (CLRTD), 0x10_004D (CLRUA)
Figure 26-18. Port Clear Output Data Registers (4-bit)
Table 26-6. CLRn (8-bit,7-bit, 6-bit, and 4-bit) Field Descriptions
Register
Bits
Name
Description
8-bit
7–0
CLRnx
Port n clear output data register bits.
1 Never returned for reads; no effect for writes
0 Always returned for reads; clears corresponding
PORTn bit for writes
7-bit
6–0
6-bit
5–0
4-bit
3–0
7-bit
7
—
Reserved, should be cleared.
6-bit
7–6
4-bit
7–4
