QUICK START GUIDE

SUMMARY OF INSTALLATION STEPS

MINIMUM REQUIRED CONFIGURATION

ACCESS METHODS

1. Install the Switch in the central telephone room

2. Install cross-connect wires with the existing premises wiring

3. Configure the Switch following the configuration shown below

4. Install the in-room filters and WallPlate CPEs

5. Connect a 12VDC wall power supply to the WallPlate, link with the Switch

6. When the link LED is solid, test the connection for speed and quality

7. Enable Line Power for the line being installed

8. Remove the wall power supply

login using console, HTTP, Telnet

IP address: 192.168.1.3

Console: 9600-8-N-1

User:

admin

Password:

system> interface dsl enable port(1-25)

system> interface remote enable port(1-25)-(1-2)

Radio Frequency Interference Requirements- FCC

Note: This equipment has been tested and found to comply with the limits for a Class A digital

device, pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable

protection against harmful interference when the equipment is operated in commercial

environment. This equipment generates, uses, and can radiate radio frequency energy and, if not

installed and used in accordance with the instruction manual, may cause harmful interference to

radio communications. Operation of this equipment in a residential area is likely to cause harmful

interference in which case the user will be required to correct the interference at his own

expense.
Radio Frequency Interference Requirements- Canada

This Class A digital apparatus complies with Canadian ICES-003.

Cet appareil numérique de la classe A est conforme à la norme NMB-003 du Canada.
Marking and European Economic Area (EEA)

WARNING: This is a Class A product. In a domestic environment this product may cause radio

interference in which case the user may be required to take adequate measures.
Statement of Compliance

Motorola/Symbol hereby declares that this device is in compliance with all the applicable

Directives, 2004/108/EC and 2006/95/EC. A Declaration of Conformity may be obtained from

http://www2.symbol.com/doc/.
T2-2500 and T3 Switch

CAUTION: For installation only in a Restricted Access Location by trained service personnel.

CAUTION: Equipment must be connected to an earthed mains socket-outlet.

CAUTION: To reduce the risk of fire, use only No. 26 AWG or larger telecommunication line cord.

CAUTION: The power supply cord plug serves as the main disconnect for the product. The socket-

outlet shall be installed near the product and be readily accessible.

CAUTION: Voltages present which are above TNV-3 (POTS) limits. A cover must be installed over

the punch down blocks with a HV (High Voltage) warning label (supplied).
The maximum operating ambient temperature is 50 degrees Celcius.
When installing the Switch in an equipment rack, consider the following potential hazards:
Elevated Operating Ambient Temperature - If installed in a closed or multi-unit rack assembly, the

operating ambient temperature of the rack environment may be greater than the room ambient.

Therefore, consideration should be given to installing the equipment in an environment compatible

with the manufacturer's maximum rated ambient temperature (Tmra).

Reduced Air Flow - Installation of the equipment in a rack should be such that the amount of air

flow required for safe operation of the equipment is not compromised.

Mechanical Loading - Mounting of the equipment in the rack should be such that a hazardous

condition is not achieved due to uneven mechanical loading.

Circuit Overloading - Consideration should be given to the connection of the equipment to the

supply circuit and the effect that overloading of circuits might have on overcurrent protection and

supply wiring. Appropriate consideration of equipment nameplate ratings should be used when

addressing this concern.

Reliable Earthing - Reliable earthing of rack-mounted equipment should be maintained.

Particular attention should be given to supply connections other than direct connections to the

branch circuit (e.g., use of power strips).
m2 and MC-802 WallPlate

CAUTION: Use only power supplies listed in the user manual

When using your telephone equipment, basic safety precautions should always be followed to

reduce the risk of fire, electric shock and injury to persons, including the following:
1. Do not use this product near water, for example, near a bath tub, wash bowl, kitchen sink or

laundry tub, in a wet basement or near a swimming pool.

2. Avoid using a telephone (other than a cordless type) during an electrical storm. There may be a

remote risk of electric shock from lightning.

3. Do not use the telephone to report a gas leak in the vicinity of the leak.

For EU Customers: All products at the end of their life must be returned to Motorola for

recycling. For information on how to return product, please go to:

www.motorola.com/recycling/weee.

Contact Motorola PBN support for access to User Guides,

Command References and detailed usage guides

email: [email protected]

T2-2500 and T3 PowerBroadband Switch
