Register Memory Map
Freescale Semiconductor A-11
IPSBAR + 0xCEC Level 3 Interrupt Acknowledge Register 0 L3IACKR0 8
IPSBAR + 0xCF0 Level 4 Interrupt Acknowledge Register 0 L4IACKR0 8
IPSBAR + 0xCF4 Level 5 Interrupt Acknowledge Register 0 L5IACKR0 8
IPSBAR + 0xCF8 Level 6 Interrupt Acknowledge Register 0 L6IACKR0 8
IPSBAR + 0xCFC Level 7 Interrupt Acknowledge Register 0 L7IACKR0 8
Interrupt Controller 1
IPSBAR + 0xD00 Interrupt Pending Register High 1 IPRH1 32
IPSBAR + 0xD04 Interrupt Pending Register Low 1 IPRL1 32
IPSBAR + 0xD08 Interrupt Mask Register High 1 IMRH1 32
IPSBAR + 0xD0C Interrupt Mask Register Low 1 IMRL1 32
IPSBAR + 0xD10 Interrupt Force Register High 1 INTFRCH1 32
IPSBAR + 0xD14 Interrupt Force Register Low 1 INTFRCL1 32
IPSBAR + 0xD18 Interrupt Level Request Register 1 ILRR1 8
IPSBAR + 0xD19 Interrupt Acknowledge Level and Priority Register 1 IACKLPR1 8
IPSBAR + 0xD48 Interrupt Control Register 1-08 ICR108 8
IPSBAR + 0xD49 Interrupt Control Register 1-09 ICR109 8
IPSBAR + 0xD4A Interrupt Control Register 1-10 ICR110 8
IPSBAR + 0xD4B Interrupt Control Register 1-11 ICR111 8
IPSBAR + 0xD4C Interrupt Control Register 1-12 ICR112 8
IPSBAR + 0xD4D Interrupt Control Register 1-13 ICR113 8
IPSBAR + 0xD4E Interrupt Control Register 1-14 ICR114 8
IPSBAR + 0xD4F Interrupt Control Register 1-15 ICR115 8
IPSBAR + 0xD50 Interrupt Control Register 1-16 ICR116 8
IPSBAR + 0xD51 Interrupt Control Register 1-17 ICR117 8
IPSBAR + 0xD52 Interrupt Control Register 1-18 ICR118 8
IPSBAR + 0xD53 Interrupt Control Register 1-19 ICR119 8
IPSBAR + 0xD54 Interrupt Control Register 1-20 ICR120 8
IPSBAR + 0xD55 Interrupt Control Register 1-21 ICR121 8
IPSBAR + 0xD56 Interrupt Control Register 1-22 ICR122 8
IPSBAR + 0xD57 Interrupt Control Register 1-23 ICR123 8
IPSBAR + 0xD58 Interrupt Control Register 1-24 ICR124 8
IPSBAR + 0xD59 Interrupt Control Register 1-25 ICR125 8
Table A-3. Register Memory Map (continued)
Address Name Mnemonic Size
MCF5282 and MCF5216 ColdFire Microcontroller User’s Manual, Rev. 3
