Mechanical Data
Freescale Semiconductor 32-3
Figure 32-2 is the pinout for the MCF5214 and MCF5216. The shaded cells illustrate the differences
between the MCF5280, MCF5281, and MCF5282 pinout.
Figure 32-2. MCF521x Pinout (256 MAPBGA)
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16
A VSS A15 A16 A18 A21 VPP PEL7 PEL0 PEL3 PAS4 NC VDDF DDATA1 PST2 PST0 VSS
B A14 A13 A17 A19 VSSF A22 PEL6 NC PEL2 NC NC VSSF DDATA0 PST1 IRQ7 IRQ6
C A12 A11 A10 A20 VDDF A23 PEL5 NC PEL1 PAS5 VPP DDATA3 PST3 IRQ5 IRQ4 IRQ3
D A9 A8 A7 A6 VDDF NC NC NC NC PEL4 VDDF DDATA2 NC IRQ2 IRQ1 CANRX
E A5 A4 A3 A2 VSS VDD VDD VDD VDD VDD VDD VSS CANTX SDA SCL
QSPI_
DIN
F A1 A0 D31 NC VDD VSS VDD VDD VDD VDD VSS VDD
QSPI_
DOUT
QSPI_
CLK
QSPI_
CS0
QSPI_
CS1
G D30 D29 D28 D27 VDD VDD VSS VSS VSS VSS VDD VDD
QSPI_
CS2
QSPI_
CS3
DRAMW
SDRAM_
CS0
H D26 D25 D24 D23 VDD VDD VSS VSS VSS VSS VDD VDD
SDRA_
CS1
SCKE SRAS SCAS
J D22 D21 D20 D19 VDD VDD VSS VSS VSS VSS VDD VDD DTOUT0 DTIN0 DTOUT1 DTIN1
K D18 D17 D16 NC VDD VDD VSS VSS VSS VSS VDD VDD DTOUT2 DTIN2 DTOUT3 DTIN3
L D15 D14 D13 D12 VDD VSS VDD VDD VDD VDD VSS VDD CS0 CS1 CS2 CS3
M D11 D10 D9 D8 VSS VDD VDD VDD VDD VDD VDD VSS NC TIP TS SIZ0
N D7 D6 D5 NC D3 URXD0 CLKOUT VDDPLL NC TEST VSTBY GPTB0 GPTA0 SIZ1 R/W OE
P D4 VDDH AN55 VRH VSSA D0 UTXD1 VSSPLL DSCLK BKPT RSTO GPTB1 GPTA1 BS3 TEA TA
R AN3 AN1 AN56 AN52 VDDA D1 URXD1 XTAL
JTAG_
EN
DSI RSTI GPTB2 GPTA2 CLKMOD0 BS1 BS0
T VSSA AN2 AN0 AN53 VRL D2 UTXD0 EXTAL TCLK DSO RCON GPTB3 GPTA3 CLKMOD1 BS2 VSS
