Register Memory Map
Freescale Semiconductor A-21
General Purpose Timer B Registers
IPSBAR +
0x1B_0000
GPTB IC/OC Select Register GPTBIOS 8
IPSBAR +
0x1B_0001
GPTB Compare Force Register GPTBCFORC 8
IPSBAR +
0x1B_0002
GPTB Output Compare 3 Mask Register GPTBOC3M 8
IPSBAR +
0x1B_0003
GPTB Output Compare 3 Data Register GPTBOC3D 8
IPSBAR +
0x1B_0004
GPTB Counter Register GPTBCNT 16
IPSBAR +
0x1B_0006
GPTB System Control Register 1 GPTBSCR1 8
IPSBAR +
0x1B_0008
GPTB Toggle-on-Overflow Register GPTBTOV 8
IPSBAR +
0x1B_0009
GPTB Control Register 1 GPTBCTL1 8
IPSBAR +
0x1B_000B
GPTB Control Register 2 GPTBCTL2 8
IPSBAR +
0x1B_000C
GPTB Interrupt Enable Register GPTBIE 8
IPSBAR +
0x1B_000E
GPTB System Control Register 2 GPTBSCR2 8
IPSBAR +
0x1B_000E
GPTB Flag Register 1 GPTBFLG1 8
IPSBAR +
0x1B_000F
GPTB Flag Register 2 GPTBFLG2 8
IPSBAR +
0x1B_0010
GPTB Channel 0 Register GPTBC0 16
IPSBAR +
0x1B_0012
GPTB Channel 1 Register GPTBC1 16
IPSBAR +
0x1B_0014
GPTB Channel 2 Register GPTBC2 16
IPSBAR +
0x1B_0016
GPTB Channel 3 Register GPTBC3 16
IPSBAR +
0x1B_0018
Pulse Accumulator Control Register GPTBPACTL 8
IPSBAR +
0x1B_0019
Pulse Accumulator Flag Register GPTBPAFLG 8
Table A-3. Register Memory Map (continued)
Address Name Mnemonic Size
