30.5
Background Debug Mode (BDM)
The ColdFire Family implements a low-level system debugger in the microprocessor hardware.
Communication with the development system is handled through a dedicated, high-speed serial command
interface. The ColdFire architecture implements the BDM controller in a dedicated hardware module.
Although some BDM operations, such as CPU register accesses, require the CPU to be halted, other BDM
commands, such as memory accesses, can be executed while the processor is running.
30.5.1
CPU Halt
Although most BDM operations can occur in parallel with CPU operations, unrestricted BDM operation
requires the CPU to be halted. The sources that can cause the CPU to halt are listed below in order of
priority:
28–22/
12–6
EDx
Setting an EDx bit enables the corresponding data breakpoint condition based on the size and
placement on the processor’s local data bus. Clearing all EDx bits disables data breakpoints.
28/12
EDLW
Data longword. Entire processor’s local data bus.
27/11
EDWL
Lower data word.
26/10
EDWU
Upper data word.
25/9
EDLL
Lower lower data byte. Low-order byte of the low-order word.
24/8
EDLM
Lower middle data byte. High-order byte of the low-order word.
23/7
EDUM
Upper middle data byte. Low-order byte of the high-order word.
22/6
EDUU
Upper upper data byte. High-order byte of the high-order word.
21/5
DI
Data breakpoint invert. Provides a way to invert the logical sense of all the data breakpoint
comparators. This can develop a trigger based on the occurrence of a data value other than the DBR
contents.
20–18/
4–2
EAx
Enable address bits. Setting an EA bit enables the corresponding address breakpoint. Clearing all
three bits disables the breakpoint.
20/4
EAI
Enable address breakpoint inverted. Breakpoint is based outside the range between ABLR
and ABHR.
19/3
EAR
Enable address breakpoint range. The breakpoint is based on the inclusive range defined
by ABLR and ABHR.
18/2
EAL
Enable address breakpoint low. The breakpoint is based on the address in the ABLR.
17/1
EPC
Enable PC breakpoint. If set, this bit enables the PC breakpoint.
16/0
PCI
Breakpoint invert. If set, this bit allows execution outside a given region as defined by PBR and PBMR
to enable a trigger. If cleared, the PC breakpoint is defined within the region defined by PBR and
PBMR.
Table 30-14. TDR Field Descriptions (continued)
Bits
Name
Description
